Cellular Repeaters Bird-DMR600
Klik pada gambar untuk memperbesar
| Harga | Rp 12.345.678,00 |
| Berat | 1400 gram |
| Ketersediaan Barang | 5 |
Lebih Lengkap Mengenai Cellular Repeaters Bird-DMR600
DMR600
Bird's DMR600 repeater platform with medium power band selective repeaters is designed for a small form factor, high performance and a long lifetime. It can be used for coverage enhancement in up to medium sized indoor environments.
KEY FEATURES- Small size and lightweight for easy installation
- Variable bandwidth up to 35M Hz depending on configuration
- High selectivity using SAW technology
- Optimal performance and minimal interference with self oscillation protection, fast AGC and link symmetry functionality.
- Operational parameters are set in a web interface, only a web browser is needed for control
- Remote control via Ethernet or Remote GateWay
- Alarms can be forwarded via SNMP to any maintenance centre
- CE Compliant
General Specifications
Gain: 50 - 80 dB in 1dB steps
Noise Figure: < 5 dB
Delay: < 7 µs
Power Supply (Optional): 12 - 30 VDC
Power Supply Included: 100-240 VDC
Power Consumption DC (12-28V): < 35 W
Dimensions (WxDxH): 11.8"2" x 8.3" (300 x 50 x 210 mm)
Weight: 3 lbs/1.4 kg
Operating Temperature DC Powered: -25 - +55 ºC
Operating Temperature AC Powered: 0 - +40 ºC
Enclosure: IP42
AVAILABLE PRODUCTS, American
| Product | System | UL Frequency Range | DL Frequency Range | Pout UL/DL, dBm (Composite) | Standard |
|---|---|---|---|---|---|
| DMR605 | 700 lower | 698-716 | 728-746 | 25 | FCC |
| DMR604 | 700 upper | 777-787 | 746-756 | 25 | FCC |
| DMR608 | Cellular | 824-849 | 869-894 | 25 | FCC |
| DMR619 | PCS1900 | 1850-1910 | 1930-1990 | 25 | FCC |
| DMR620 | AWS |
1710-1755 | 2110-2155 | 25 | FCC |
AVAILABLE PRODUCTS, European Cellular
| Product | System | UL Frequency Range | DL Frequency Range | Pout UL/DL, dBm (Composite) | Standard |
|---|---|---|---|---|---|
| DMR601 | TETRA, Public Safety |
380-385 | 390-395 | 19 | ETSI |
| DMR602 | TETRA, Commercial |
410-415 | 420-425 | 19 | ETSI |
| DMR603 | TETRA, Commercial |
415-420 | 425-430 | 19 | ETSI |
| DMR604 | CDMA450 |
453-457.5 | 463-467.5 | 25 | FCC |
| DMR606 | GSM-R |
876-880 | 921-925 | 19 | ETSI |
| DMR609 | EGSM900 |
880-915 | 925-960 | 19 | ETSI |
| DMR618 | GSM1800 |
1710-1785 | 1805-1880 | 19 | ETSI |
| DMR621 | UMTS |
1920-1980 | 2110-2170 | 23 (DL), 20(UL) | 3GPP |
